EEW Explosion Proof Emergency Light ESL102

Applicable areas:

Ex-Mark: Ⅱ2G Ex de ib ⅡC T6 Gb / Ⅱ2D Ex tb ⅢC T80℃ Db
                II 2G Ex de ib q IIC T6 Gb, II 2D Ex tb IIIC T80°C Db.
ATEX Cert. No.: ECM 18 ATEX 4870
Operable in hazardous areas: IIA,IIB,IIC Explosion hazardous gas Zone1 and Zone2.
Operable in: Combustible dust IIIA,IIIB,IIIC Zone 21 and Zone 22

Features:

• Light source: LED, DC 3.0~3.4V, 140-160mA
• Ingress protection: IP65 – Fully sealed to prevent dust and moisture intrusion
• Anti-corrosion grade: WF1
• Operable ambient temperature: -20°C to 40°C
• Emergency time: ≥90 minutes
• Emergency power: 4W
• Emergency switching time: ≤0.25 seconds
• Emergency luminous flux output: ≥50lm
• Battery: Nickel-Cadmium 3.6V 0.7Ah
• Charging time: 24 hours
• LED status indicator
• Test button
• Cable entry: G3/4″
• Cable outer diameters: 9mm ~ 14mm

Material:

• Powder coated diecast aluminium alloy fixture – Anti-corrosion properties
• Tempered glass light cover
• Stainless steel fastener

Signage available:

Applications:

Oil refinery, Chemical plant, Storage silos and other applicable lighting application

Standards:

Designed and manufactured in compliance with

EN 60079-0:2012 + A11:2013
EN 60079-1:2014
EN 60079-5:2015
EN 60079-7:2015
EN 60079-11:2012
EN 60079-31:2014
